The Stellar P3 PowerPlant takes your incoming AC power and converts it to DC, similar to what comes out of a battery, and then, with patented PS Audio technology, regenerates and produces new sine-wave-perfect, regulated, high-current AC power. In the process of regeneration, any problems commonly found on your power line, such as low voltage, distorted waveforms, sagging power, flat-topping, and noise are eliminated. The input voltage to the PowerPlant is fully protected by state-of-the-art clamping devices and the output is fully regulated so even large voltage swings that would normally damage connected equipment are made safe by either clamping or regulating. With your system powered directly from the ouput of the Stellar P3, dynamics and openness are breathtaking. New voices, new harmonics, and a renewed sense of musicality are yours the moment the P3 starts up.This is one of the most important pieces of audio equipment you can own, building a firm and reliable foundation for your system that will serve you for years to come. Not suited for class A or A/B amplification in 220V models.



Features
Specifications - Stellar PowerPlant 3
Environment Specification |
U.S./Japan |
Europe/Asia |
Location | Indoor use only | Indoor use only |
Duty Cycle | Suitable for continuous operation | Suitable for continuous operation |
Moisture Sensitivity | Not sealed against moisture | Not sealed against moisture |
Operating Humidity | <80%rh | <80%rh |
Storage Temperature | -40C to +40C | -40C to +40C |
Operating Temperature | 0C to 40C | 0C to 40C |
Electrical Supply Nominal Rating | US - 120V 15A 60Hz JP - 100V 15A 50/60Hz |
230V 10A 50/60Hz |
Instrument Specification |
U.S./Japan |
Europe/Asia |
Unit Dimensions | 17” W x 12” D x 3.25” H (43cm x 30.48cm x 8.255cm) | 17” W x 12” D x 3.25” H (43cm x 30.48cm x 8.255 cm) |
Unit Weight | 31.4 lbs ( 14.24 kg) | 31.4 lbs ( 14.24 kg) |
Shipping Dimensions | 22” x 17” x 8” (55.88cm x 43.18cm x 20.32cm) | 17” W x 12” D x 3.25” H (43cm x 30.48cm x 8.255 cm) |
Shipping Weight | 39.4 lbs (17.87 kg) | 39.4 lbs (17.87 kg) |
Nominal Input Voltage | US - 108 – 145 VAC JP - 85 – 125 VAC |
200 –270 VAC |
Maximum Continuous Load | US - 300VA JP - 300VA |
300VA |
Maximum Peak Load (30 seconds) | 1000VA | 1000VA |
Voltage Regulation | <0.1% | <0.2% |
Typical Output THD | <0.3% | <0.3% |
Output Impedance | <0.008 ohm | <0.008 ohm |
Efficiency @ 300VA | >85% | >85% |
Input Frequency | 45 – 65 Hz | 45 – 65 Hz |
Energy Dissipation | 680J | 850J |
Peak Current Surge | 60,000A | 60,000A |
Max Surge Voltage | 6,000V | 6,000V |
Clamp Level | 340V | 800V |
DC Trigger | None | None |
Standby Power Consumption |
25 Watts |
25 Watts |
