Rated at 350 Watts into 8Ω and 700 Watts into 4Ω, the M700 combines the best of two worlds: ultra linear, high-current, Class D technology for the output stage; a discrete, Class A MOSFET based Analog Cell for the all-important input stage. The Stellar M700 captures the rich, full-bodied essence of recorded music and presents it to your loudspeakers with authority and grace, never a hint of glare or unnaturalness. The M700 is faithful to the music like few amplifiers are. Listeners are constantly surprised at the width and depth of the M700's soundstage; its preservation of the smallest details in reverb, room acoustics, and musical overtones; its commanding presence without intrusion; its delicate handling of subtle shadings; its authority as it grabs hold of the loudspeaker and breezes through even the most complex musical passages.
Features
Specifications - M700 Amplifier
Stellar M700 Mono Amplifier |
|
| Unit Weight | 13 lbs [5.9 kg] (each) |
| Unit Dimensions | 17”W x 3”H x 12”D (13"D w/connectors) 17”W x 6”H x 12”D (Stacked) |
| Shipping Weight | 16.5 lbs [7.5 kg] (each) |
| Shipping Dimensions | 22”W x 8”H x 17”D (each) |
| Color Options | Black Silver |
| Voltage Options (Factory set only) |
Japan 100V North America 120V Europe/Asia/Australia/New Zealand 230V |
| Mains Power Inputs | IEC C14 |
| Idle Power Consumption | 23W |
| Accessories Included | US (NEMA 5-15P) (all versions) Schuko (CEE7/7) (230V version) UK (BS 1363) (230V version) |
| Audio Inputs | RCA (Unbalanced) XLR (Balanced) |
| Speaker Outputs | Copper base nickel plated binding posts (2 pair) |
| DC Trigger Input | 3.5mm 5-15VDC |
| Warranty | 3 years parts and labor |
Signal |
|
| Gain | 30.5dB +/-0.5dB |
| Sensitivity for rated output power | 1.6V |
| Noise | 1kHz@700 Watts < -105dB |
| Input impedance | Unbalanced 50KΩ Balanced 100KΩ |
| Output Impedance | 50Hz, 2.8VRMS <0.007Ω |
| Damping factor | 50Hz. 2.8VRMS 8Ω >1100 4Ω >550 |
| Frequency Response | 2.8VRMS into 4Ω 10Hz – 20KHz +/- 0.5dB 10Hz – 50KHz +0.1/-3.0dB |
THD&IM |
|
| 1KHz, 1W/4Ω | <0.02% |
| 10-20KHz, 1W/4Ω | <0.02% |
| 10-50KHz, 1W/4Ω | < 0.05% (90kHz BW) |
| 1KHz, 87.5W/4Ω | < 0.015% |
Output Power |
120vac mains, 1kHz, 1% THD |
| 8Ω | 350W minimum |
| 4Ω | 700W minimum |
| 2Ω | Stable for musical transients |
