Stellar PowerPlant 3

Stellar PowerPlant 3

Our most affordable AC regenerator, the P3 protects, purifies, and powers sources, as well as small to medium sized systems.
The Stellar Power Plant 3 stands on the shoulders of giants. Built as an evolution from our renowned P12, P15, and P20 the P3 is our most affordable regenerator – perfect for powering sources and small to medium systems. Power Plants generate sine-wave-perfect, regulated, high current AC power from your home’s AC. Problems on your power line such as low voltage, distorted waveforms, sagging power, and noise are eliminated and the power quality enhanced. The Stellar P3 PowerPlant provides greatly improved performance and safety from just plugging into the wall socket, along with far better dynamics, more authoritative bass, and a much bigger, more open soundstage than any passive power conditioner on the market.
Regular price $2,999.00 USD
Regular price Sale price $2,999.00 USD
On Sale Sold out
Shipping calculated at checkout.
Trade-in
call
TALK TO A HI-FI SPECIALIST
View full details
  • Design

    The Stellar P3 PowerPlant features an ultra-low impedance analog AC power amplifier, pure DSD FPGA based analog sine wave regenerator, and low distortion high-dynamic-peak-capable outputs found only in PS Audio PowerPlants. Designed with elegant simplicity in mind, the P3 is a plug and play device that will provide you with perfect power and worry free protection from surges, spikes, and ugly power without any fuss. Regulate, remove distortion, and get better performance.

  • Application

    The P3 is the perfect companion for improving system performance and ensuring a safe environment for you Hi-Fi system. Providing 300 watts of continuous power output and peaks of 1000 watts, the P3 is just right for source gear or an entire systems running small to medium class AB amps or larger high-efficiency Class D amps like the Stellar M700 monoblocks. The P3 will bring forth all that's possible from your HiFi system, ensuring you get the same great performance every time you listen.

    Technology

    The Stellar P3 PowerPlant takes your incoming AC power and converts it to DC, similar to what comes out of a battery, and then, with patented PS Audio technology, regenerates and produces new sine-wave-perfect, regulated, high-current AC power. In the process of regeneration, any problems commonly found on your power line, such as low voltage, distorted waveforms, sagging power, flat-topping, and noise are eliminated. The input voltage to the PowerPlant is fully protected by state-of-the-art clamping devices and the output is fully regulated so even large voltage swings that would normally damage connected equipment are made safe by either clamping or regulating. With your system powered directly from the ouput of the Stellar P3, dynamics and openness are breathtaking. New voices, new harmonics, and a renewed sense of musicality are yours the moment the P3 starts up.This is one of the most important pieces of audio equipment you can own, building a firm and reliable foundation for your system that will serve you for years to come. Not suited for class A or A/B amplification in 220V models.

    • BUILT IN BOULDER
    • 300 WATTS CONTINUOUS OUTPUT
    • 500 WATTS SHORT-TERM OUTPUT
    • 900 WATTS PEAK OUTPUT
    • 1000 WATTS FILTERED OUTPUT
    • 3x LOWER IMPEDENCE THAN P5 POWER PLANT
    • 6x OUTLETS US
    • 15AMP AC INPUT US
    • RANGE 95 – 145 VAC US
    • 4 EU/AU/GR/UK OUTLETS
    • 10AMP AC INPUT EU/AU/GR/UK
    • 230 VOLT REGULATED EU/AU/GR/UK
    • RANGE 200 –285VAC EU/AU/GR/UK
    • 100% REGENERATED AC
    • MULTIWAVE
    • CLEANWAVE
    • PURE SINE WAVE
    • REMOTE CONTROL
    • 48 LBS.
    • 17W x 4H x 14D
    1 of 20

    Specifications - Stellar PowerPlant 3

    Environment Specification

    U.S./Japan

    Europe/Asia

    Location Indoor use only Indoor use only
    Duty Cycle Suitable for continuous operation Suitable for continuous operation
    Moisture Sensitivity Not sealed against moisture Not sealed against moisture
    Operating Humidity <80%rh <80%rh
    Storage Temperature -40C to +40C -40C to +40C
    Operating Temperature 0C to 40C 0C to 40C
    Electrical Supply Nominal Rating US - 120V 15A 60Hz
    JP - 100V 15A 50/60Hz
    230V 10A 50/60Hz

    Instrument Specification

    U.S./Japan

    Europe/Asia

    Unit Dimensions 17” W x 12” D x 3.25” H (43cm x 30.48cm x 8.255cm) 17” W x 12” D x 3.25” H (43cm x 30.48cm x 8.255 cm)
    Unit Weight 31.4 lbs ( 14.24 kg) 31.4 lbs ( 14.24 kg)
    Shipping Dimensions 22” x 17” x 8” (55.88cm x 43.18cm x 20.32cm) 17” W x 12” D x 3.25” H (43cm x 30.48cm x 8.255 cm)
    Shipping Weight 39.4 lbs (17.87 kg) 39.4 lbs (17.87 kg)
    Nominal Input Voltage US - 108 – 145 VAC
    JP - 85 – 125 VAC
    200 –270 VAC
    Maximum Continuous Load US - 300VA
    JP - 300VA
    300VA
    Maximum Peak Load (30 seconds) 1000VA 1000VA
    Voltage Regulation <0.1% <0.2%
    Typical Output THD <0.3% <0.3%
    Output Impedance <0.008 ohm <0.008 ohm
    Efficiency @ 300VA >85% >85%
    Input Frequency 45 – 65 Hz 45 – 65 Hz
    Energy Dissipation 680J 850J
    Peak Current Surge 60,000A 60,000A
    Max Surge Voltage 6,000V 6,000V
    Clamp Level 340V 800V
    DC Trigger None None
    • Bob Barrett, Future Audiophile

      "The value-priced Stellar PowerPlant 3 is without a peer..."
