Written by Russ Welton

Does this complaint sound familiar? “I have a small room and I just can’t get it to sound good.”

Many if not most of us have small to medium-sized listening rooms. One of the biggest problems of small room acoustics is that of the first reflections off of the walls, floors and ceilings. (For those who may be newer to the subject, first reflection points are just what the term implies – the indirect sound from the loudspeakers that reflects or bounces off the side walls, floor, and ceiling. These arrive later in time than the direct sound from the speakers, and can degrade the overall sound, frequency response, and imaging.) But there are many other considerations I’d also like to cover.

Put simply, small rooms encompass practically all domestic living spaces, with the exceedingly rare exception of someone’s domestic listening space being in a mansion or a barn, or rarer still, on par with an auditorium or hall. For most of us, our listening spaces constitute the “small” or “really small” category.

It’s helpful to realize that the bigger our room is, the more the speakers influence the overall sound, and conversely, the smaller the room, the greater the room’s effect on what we hear. (That said, it’s important to match the size of the speakers to the size of the room, a topic we’ll get into in a future installment. This also assumes you’re not doing near-field listening close to the speakers, which mitigates a lot of room issues but is not for everyone.) And when we talk about rooms, a big part of what we’re really talking about are the actual surfaces of the room, which define what we hear along with the effect of the room dimensions themselves.

One outstanding and mostly overlooked example of how to improve your room acoustics is that of installing a suspended or drop ceiling with absorptive tiles. (Metal ceiling tiles need not apply!) Because of the fibrous nature of acoustical tiles and the volume of air between the tiles and the ceiling, this acts as a huge ceiling-based bass trap, and is excellent for quelling unwanted vertically-traveling bass nodes (but not the horizontal ones). If floor footprint area is at a serious premium, installing a drop ceiling could be especially worth considering, albeit it’s a relatively expensive and not necessarily practical or aesthetically pleasing option – and you still have the issue of having to manage your horizontally-traveling reflection points and room nodes, areas of bass peaks and dips that compound and cancel each other. (See my articles, “Sub Missive” in Issue 137, “Subliminal or Sublime Bass?” in Issue 138, “Standing Room Only” in Issue 139, “The Audio Butterfly Effect” in Issue 143 and “Finding a Place for Bass” in Issue 144 for more insights.)

Okay, okay, you may well hate this suspended ceiling idea. Don’t worry; there are plenty of other ways to optimize the acoustics of smaller listening rooms. Another approach is the use of multiple subwoofers, rather than just one, or as in many peoples’ cases, none at all. The use of multiple subs can create a more even in-room bass response, as discussed in “Standing Room Only” and “The Audio Butterfly Effect.”


A small- to medium-sized listening space. Courtesy of Quang Nguyễn.

A small- to medium-sized listening space. Courtesy of Quang Nguyễn.


If you’re a veteran audio person, you may have heard about the room transition frequency, also known as the Schroeder frequency, and that making EQ adjustments to our room’s frequency response above this frequency doesn’t help our cause very much. Why? The short answer is that below the Schroeder frequency, typically between around 100 and 250 Hz, the room acts as a resonator, and above the Schroeder frequency, as a reflector and diffusor of sound.

Therefore, our room’s response can be broken down into two basic parts: the bass region where low-frequency room modes have a significant effect; and the stochastic or “random behavior” zone. The Schroeder frequency is the transition from the bass frequencies and the stochastic zone. (The Schroeder frequency is lower in a smaller room and higher in a larger room.)

The low-frequency region is where room modes create dips and peaks in the bass response, the result of areas of bass cancellation and reinforcement. When room response is measured you can see these peaks and troughs quite easily. (Today there are readily-available software utilities like REW Room EQ Wizard that make sophisticated measurements available to home users.)

The stochastic – midrange to treble – zone also contains modes, peaks and troughs, but they’re much less severe, perhaps more like a closed accordion with the bellows pressed flat up against each other, and the dips and peaks are now so close to each other that they are no longer distinguishable. (Note that because of the stochastic – random – nature of the room’s behavior, you might see subtle changes every time you take a room measurement, but from a practical standpoint, this won’t be anything that you might actually hear as a difference.

So, what can we do about these early reflections and tame our room’s response to them? The first thing is to identify where the points of first reflections are. There is a practical way of identifying them which has become a time-honored audiophile procedure. Get a friend to hold a mirror along the left wall while you sit in your listening position. He should hold the mirror at your eye level. Then ask your friend to move along the wall until you can see the reflection of your left speaker’s tweeter in the mirror. This will be your first reflection point for the left speaker. Mark this point, as this is where you’ll want to apply absorptive room treatment. Repeat the procedure for the right wall and speaker.


Absorptive material placed at the points of first reflections on the side walls. (Other room treatment is also shown.) Courtesy of GIK Acoustics.

Absorptive material placed at the points of first reflections on the side walls. (Other room treatment is also shown.) Courtesy of GIK Acoustics.


We will cover some suggested room treatment considerations in more depth in later installments. But addressing the first reflection points will go a long way in improving the sound of your listening room, right off the bat.

Making EQ adjustments to compensate for low-frequency room nodes is an effective technique for evening out in-room bass response. By why is it that making EQ adjustments in the stochastic zone’s frequencies is generally less significant for improving our sound? It’s because the amount of audio information here is so great that your brain operates as a filter, and ignores a lot of the information. It’s also because, as noted, the higher-frequency modes are very close together and not as severe. EQ can certainly be effective in the midrange and high frequencies to address other issues, like a speaker that’s overly bright, but it should be used judiciously so as not to degrade the overall signal integrity more than is really necessary. Be cautious to generally only adjust to reduce “gremlin peaks “rather than boost vacuous dips, for example.

Add to this the reality is the fact that the measurements obtained by the measurement microphone are not truly representative of what your ears are hearing. Your ears come in pairs, each in a different position to each other, whereas your measurement mic will most likely be a single omnidirectional microphone. The mic is only going to be able to give a representation of what audio signals are being put into the room. Your ears hear a much more sophistically processed and filtered stereo sound, compared to the microphone, which takes in everything and does not filter what it “hears.” (And keep in mind that different measurement mics can have different frequency responses.)

Also consider: microphones sample the sum total of a room’s direct and reflected sound, and off-axis response without differentiating between any of it, as opposed to what your ears hear. That said, measurement software and microphones are valuable tools in measuring the frequency response of rooms, something that can’t be done “by ear” alone!

In Part Two of this series, we’ll briefly look at what may compound the problem of the measurement microphone’s sampling limitations in making adjustments for something other than what we actually hear, and what you can do to help mitigate it in ways to produce great-sounding results. We’ll also cover some free and very inexpensive ways to test your room’s behavior so that you can choose how you wish to best address reflections; look at typical problem areas which very small rooms are blighted with; and identify some pitfalls to avoid. We will also consider some of the benefits of controlled-dispersion speakers, and circumstances where you may choose to use diffusion over absorption.
